| Flat vice band saw KSU-180FV |
|
|
 |
|
|
|
|
Safe and No pollution
· No sparks, noise and dusts.
Rapid speed improves work efficiency.
|
|
 |
|
|
KSI Band saw is built on base, on which either a flat vice or a chain vice can be mounted depending on its usage.
Usage : Cutting for a steel pipe, water-supply pipe, lining steel pipe, cable pipe, PVC pipe, resin pipe, cast iron pipe, stainless steel pipe, steel material, rectanggular pipe, round bar, aluminum, etc.
|
|
|
| ■ Specifications |
|
| Model |
KSU-180FV |
| Vice type |
Flat Vice |
| Cutting capacity |
Pipes |
Ø180mm / □150mm |
| Round bar (Soft steel bar) |
Ø80mm |
| Angle cut |
Ø77mm / □75mm |
| Motor |
Single-phase, Induction motor, 300W, 60Hz |
| Blade Size |
13 × 0.65 × 1,638mm |
| Blade Speed |
48mpm |
| Dimension |
990(L) × 400(W) × 390(H)mm |
| Packing Size |
1,010(L) × 430(W) × 470(H)mm |
| N.W/G.W |
48.5kg / 53kg |
|
|
| ■ Features |
|
 |
|
 |
| Chain vice-mounted KSU Bans saw (optional) |
|
Possible to cut small objectives to the desired angles. |
 |
|
 |
| Possible to cut right angle due to imporved cutting precision. |
|
It can be easily fixed. |
 |
|
 |
| Easy to exchange blades depending on the cutting materials, and to adjust the load velocity accordingly. |
|
Strong and Quick fixing function with rapid winding. |
 |
|
 |
| Possible to cut to 45° angle with the flat vice (Model:KSU-180FW) |
|
Possible to cut a bundle of the same standard materials at one go (Model:KSU-180CV) |
|
|
|
