■ Products > Pipe threading machine
Pipe threading machine REX type
Lightweight, Easy-to-Carry and Economically Priced Models
These are compact, lightweight, portable and economical pipe Threading machines. Despite compactness, enough threading space permits easy chip disposal and they handle the work of a heavy threader, further, a triple filtering system keeps threading oil from contamination for longer life.
Specifications
Model Name N 40A N 50A
Threading Capacity ½" - 1½" ½" - 2"
Voltage(50/60Hz)(V)AC 10/220/240 (60Hz) 110/220/240 (60Hz)
Motor Single-Phase(W) Series motor 650W Series motor 750W
Rotation Speed(unloaded)(r.p.m) 40 32
Net Weight(kg) 40 58.5
Dimensions from (L)×(W)×(H)mm 540×380×375 570×470×420
☞ Votage made to order
Specifications
Model Name N 80A(3”)-C N 100A
Threading Capacity ½" - 3" ½" - 4"
Voltage(50/60Hz)(V)AC 110/220/240 (60Hz) 110/220 (60Hz)
Motor Single-Phase(W) Series motor 750W Series motor 1100W
Rotation Speed(unloaded)(r.p.m) 25 12.23.40
Net Weight(kg) 69 159
Dimensions from (L)×(W)×(H)mm 745×450×450 940×640×620
☞ Votage made to order
